QHIA:
Lub Toppo Marco Linear tau dhau los ua qhov nrov tshaj plaws linear luminaire ntawm kev ua lag luam. Qhov no ntau yam LED luminaire nta adjustable CCT thiab wattage nqis, muab kev yooj yim rau ntau yam teeb pom kev zoo xav tau. Lub Marco Linear tuaj yeem ntsia tau ua lub teeb pom kev zoo lossis ua ib qho LED pendant linear teeb, ua tsaug rau ntau yam khoom siv xws li dai cov khoom siv thiab cov lem. Nws muaj nyob rau hauv cov xim dawb, grey thiab dub tiav, tso cai rau nws mus ua seamlessly kev koom ua ke rau ntau yam kev tsim qauv. Tsis tas li ntawd, Marco Linear Profile Light muaj nyob rau hauv kev xaiv uplight thiab downlight, tso cai rau cov neeg siv khoom los kho cov teeb pom kev zoo rau lawv cov kev xav tau tshwj xeeb.
|
Diffuser |
UGR |
Order Code |
Rated zog |
LM/W |
Lumen |
Khoom Dimension |
Muaj nuj nqi |
|
Prismatic |
UGR<22 |
LL400-04B-AT1-40F01 |
20-40W |
Typ.130 |
Ib. 2600-5200 |
L1150xW60xH80 |
RAU-OFF |
|
Prismatic |
UGR<22 |
LL400-04B-AT1-40V01 |
20-40W |
Typ.130 |
Ib. 2600-5200 |
L1150xW60xH80 |
PWM (For MS) |
|
Prismatic |
UGR<22 |
LL400-04B-AT1-40D01 |
20-40W |
Typ.130 |
Ib. 2600-5200 |
L1150xW60xH80 |
DALI |
|
Prismatic |
UGR<22 |
LL400-05B-AT1-50F01 |
30-50W |
Typ.130 |
Ib., 3900-6500 |
L1437xW60xH80 |
RAU-OFF |
|
Prismatic |
UGR<22 |
LL400-05B-AT1-50V01 |
30-50W |
Typ.130 |
Ib., 3900-6500 |
L1437xW60xH80 |
PWM (For MS) |
|
Prismatic |
UGR<22 |
LL400-05B-AT1-50D01 |
30-50W |
Typ.130 |
Ib., 3900-6500 |
L1437xW60xH80 |
DALI |
|
Prismatic |
UGR<22 |
LL400-06B-AT1-60F01 |
40-60W |
Typ.130 |
Ib. 5200-7800 |
L1723xW60xH80 |
RAU-OFF |
|
Prismatic |
UGR<22 |
LL400-06B-AT1-60V01 |
40-60W |
Typ.130 |
Ib. 5200-7800 |
L1723xW60xH80 |
PWM (For MS) |
|
Prismatic |
UGR<22 |
LL400-06B-AT1-60D01 |
40-60W |
Typ.130 |
Ib. 5200-7800 |
L1723xW60xH80 |
DALI |
|
Opal |
/ |
LL410-04B-AT1-40F01 |
20-40W |
Typ.150 |
Typ.3000-6000 |
L1150xW60xH80 |
RAU-OFF |
|
Opal |
/ |
LL410-04B-AT1-40V01 |
20-40W |
Typ.150 |
Typ.3000-6000 |
L1150xW60xH80 |
PWM (For MS) |
|
Opal |
/ |
LL410-04B-AT1-40D01 |
20-40W |
Typ.150 |
Typ.3000-6000 |
L1150xW60xH80 |
DALI |
|
Opal |
/ |
LL410-05B-AT1-50F01 |
30-50W |
Typ.150 |
Typ.3000-6000 |
L1437xW60xH80 |
RAU-OFF |
|
Opal |
/ |
LL410-05B-AT1-50V01 |
30-50W |
Typ.150 |
Typ.3000-6000 |
L1437xW60xH80 |
PWM (For MS) |
|
Opal |
/ |
LL410-05B-AT1-50D01 |
30-50W |
Typ.150 |
Typ.3000-6000 |
L1437xW60xH80 |
DALI |
|
Opal |
/ |
LL410-06B-AT1-60F01 |
40-60W |
Typ.150 |
Typ.3000-6000 |
L1723xW60xH80 |
RAU-OFF |
|
Opal |
/ |
LL410-06B-AT1-60V01 |
40-60W |
Typ.150 |
Typ.3000-6000 |
L1723xW60xH80 |
PWM (For MS) |
|
Opal |
/ |
LL410-06B-AT1-60D01 |
40-60W |
Typ.150 |
Typ.3000-6000 |
L1723xW60xH80 |
DALI |
|
Reflector |
UGR<17 |
LL420-04B-RT1-40F01 |
20-40W |
Typ.150 |
Typ.3000-6000 |
L1150xW60xH80 |
RAU-OFF |
|
Reflector |
UGR<17 |
LL420-04B-RT1-40V01 |
20-40W |
Typ.150 |
Typ.3000-6000 |
L1150xW60xH80 |
PWM (For MS) |
|
Reflector |
UGR<17 |
LL420-04B-RT1-40D01 |
20-40W |
Typ.150 |
Typ.3000-6000 |
L1150xW60xH80 |
DALI |
|
Reflector |
UGR<17 |
LL420-05B-RT1-50F01 |
30-50W |
Typ.150 |
Qauv: 4500-7500 |
L1437xW60xH80 |
RAU-OFF |
|
Reflector |
UGR<17 |
LL420-05B-RT1-50V01 |
30-50W |
Typ.150 |
Qauv: 4500-7500 |
L1437xW60xH80 |
PWM (For MS) |
|
Reflector |
UGR<17 |
LL420-05B-RT1-50D01 |
30-50W |
Typ.150 |
Qauv: 4500-7500 |
L1437xW60xH80 |
DALI |
|
Reflector |
UGR<17 |
LL420-06B-RT1-60F01 |
40-60W |
Typ.150 |
Qauv: 6000-9000 |
L1723xW60xH80 |
RAU-OFF |
|
Reflector |
UGR<17 |
LL420-06B-RT1-60V01 |
40-60W |
Typ.150 |
Qauv: 6000-9000 |
L1723xW60xH80 |
PWM (For MS) |
|
Reflector |
UGR<17 |
LL420-06B-RT1-60D01 |
40-60W |
Typ.150 |
Qauv: 6000-9000 |
L1723xW60xH80 |
DALI |
|
Lens |
UGR<14 |
LL430-04B-CT1-40F01 |
20-40W |
Typ.160 |
Ib. 3200-6400 |
L1150xW60xH80 |
RAU-OFF |
|
Lens |
UGR<14 |
LL430-04B-CT1-40V01 |
20-40W |
Typ.160 |
Ib. 3200-6400 |
L1150xW60xH80 |
PWM (For MS) |
|
Lens |
UGR<14 |
LL430-04B-CT1-40D01 |
20-40W |
Typ.160 |
Ib. 3200-6400 |
L1150xW60xH80 |
DALI |
|
Lens |
UGR<14 |
LL430-05B-CT1-50F01 |
30-50W |
Typ.160 |
Typ.4800-8000 |
L1437xW60xH80 |
RAU-OFF |
|
Lens |
UGR<14 |
LL430-05B-CT1-50V01 |
30-50W |
Typ.160 |
Typ.4800-8000 |
L1437xW60xH80 |
PWM (For MS) |
|
Lens |
UGR<14 |
LL430-05B-CT1-50D01 |
30-50W |
Typ.160 |
Typ.4800-8000 |
L1437xW60xH80 |
DALI |
|
Lens |
UGR<14 |
LL430-06B-CT1-60F01 |
40-60W |
Typ.160 |
Ib. 6400-9600 |
L1723xW60xH80 |
RAU-OFF |
|
Lens |
UGR<14 |
LL430-06B-CT1-60V01 |
40-60W |
Typ.160 |
Ib. 6400-9600 |
L1723xW60xH80 |
PWM (For MS) |
|
Lens |
UGR<14 |
LL430-06B-CT1-60D01 |
40-60W |
Typ.160 |
Ib. 6400-9600 |
L1723xW60xH80 |
DALI |
